30 years trusted by NZ Kiwifruit orchardists
The AgSteel™ range is produced with pre galvanised GS300 tube which features a Z275 (ZB135/135) coating with external weld seam zinc repair, ensuring coating continuity.
Manufactured using New Zealand made, continuously hot-dipped galvanised G250 steel coil.
The product features a smooth and consistent surface finish, is highly formable and is particularly suitable for outdoor and corrosion prone environments where long term durability is essential.
| Base Material | Continuously hot-dip galvanised (Galvsteel® G250) |
| Yield Strength | 250MPa (BM) |
| Tensile Strength | 320 MPa (BM) |
| Base Material Standard | (GS): AS/NZS 1365:1996 (R2016), AS 1397:2021 |
| Product standard | AS 1450 |
| Surface Finish | Z275 coating (both sides). Medium Spangle |
| AgBeam | 64 x 38 x 1.15mm Standard, 68 x 38 x 1.55mm Heavy |
| AgJoiner | 68 x 43 x 1.55mm x 400mm Standard, 68 x 43 x 1.85mm x 400mm Heavy |
| AgBrace Flat End | 1.2m x 1.15mm and 1.85m x 1.15mm |
| AgBrace Scallop End | 1.2m x 1.15mm and 1.85m x 1.15mm |
| AgStringing Poles | 31.8mm diameter, 1.6 guage, available in 4.0m, 4.5m & 5.0m |
| AgTriPosts | 1.8m, 1.85m and 1.9m lengths, supplied with three 22mm diameter x 600mm long galvanized steel pins |
| Yield strength | Tensile strength | EI % on Lo=50mm |
|---|---|---|
| 250 MPa | 320 MPa | 27 |
End-to-end manufacturing, streamlined. Design, prototyping, and production — all managed in-house for precision and control.
