Hot-Rolled Pickled & Oiled | HR350

Hot-Rolled Pickled & Oiled | HR350 Specifications

Produced from New Zealand made, hot-rolled, pickled, and oiled steel coil.

HR350 provides a clean, consistent semi-bright finish thanks to pickling, oiling, and skin-passing, with OD accuracy comparable to CR250.
The higher yield strength delivers improved performance in brackets, supports, frames, and other applications exposed to greater physical loads.
Excellent dimensional stability and weldability make it suitable for a wide range of medium-duty fabrications.

Base Material	Hot-rolled pickled & oiled (TUBE 300 Hot-Rolled)
Yield Strength	285MPa (BM)
Tensile Strength	380 MPa (BM)
Base Material Standard	(HRPO): AS/NZS 1365:1996 (R2016).
Product standard	AS 1450
Surface Finish	Steel grey, semi-bright finish
Coating Suitability	Excellent for Paint and Hot Dip Galvanising Good for Powder Coating and Electroplating Poor for Chrome Plating
Standard stocked lengths	5.5m. Custom lengths available.
Tube Profile	Round, Square, Rectangle, Flat-Sided Oval, Oval
Tube Thickness	From 2.0mm to 2.5mm
Size Range - Round	From 15.9mm – 50.8mm
Size Range - Square	From 19.1mm to 50.8mm
Size Range - Rectangle	50.8 x 25.4mm
Size Range - FSO	97.0mm x 42.0mm
Size Range - Oval	31.8mm x 17.1mm
Typical Applications:	Racking, cargo barriers, seat frames

Yield strength	Tensile strength	EI % on Lo=50mm
285 MPa	380 MPa	30

Size (mm)	Product Type & Gauge (mm)	Finish	Nom Linear mass (kg/m)					Length per pack
Size (mm)	HR350	Finish	1.2	1.4	1.6	2.0	2.5	Length per pack
9.5			0.25	0.28	0.31			100
12.7			0.32	0.39	0.44	0.52		100
15.9	2.0		0.43	0.50	0.57	0.67		100
19.1			0.51	0.61	0.68	0.83	1.02	100
22.2			0.61	0.72	0.81	0.98	1.21	100
25.4	2.0, 2.5		0.71	0.83	0.93	1.15	1.41	100
28.6			0.78	0.94	1.07	1.32	1.69	48
31.8	2.5		0.87	1.04	1.17	1.43	1.80	48
34.9			0.99	1.15	1.30	1.60	2.00	48
38.1	2.5		0.87	1.04	1.17	1.43	1.80	48
41.3			1.15	1.38	1.52	1.89	2.42	48
44.5	2.5		1.06	1.49	1.65	2.03	2.52	48
47.6			1.35	1.57	1.78	2.19	2.78	48
50.8	2.5		1.42	1.67	1.88	2.35	3.02	48
54.0			1.56	1.82	2.03	2.53	3.14	48
57.2			1.61	1.89	2.14	2.66	3.33	24
60.3			1.72	2.00	2.28	2.80	3.60	24
63.5			1.71	2.09	2.39	2.99	3.79	24
69.9				2.35	2.67	3.23	4.16	24
76.2				2.56	2.89	3.59	5.47	24
88.9					3.44	4.28	5.33	10
101.6					3.95	4.91	6.11	10
127.0					4.87	6.04	7.68	8
152.4					5.87	7.57	9.24	8

Size (mm)	Product Type & Gauge (mm)	Finish	Nom Linear mass (kg/m)					Length per pack
Size (mm)	HR350	Finish	1.2	1.4	1.6	2.0	2.5	Length per pack
12.7x12.7			0.41	0.48	0.53			100
15.9x15.9			0.51	0.60	0.66	0.83		100
19.1x19.1	2.0		0.64	0.75	0.83	1.00		100
22.2x22.2			0.78	0.89	1.03	1.25		100
25.4x25.4	2.5		0.89	1.03	1.17	1.42	1.75	100
31.8x31.8	2.5		1.11	1.31	1.48	1.79	2.24	50
34.9x34.9			1.22	1.42	1.63	2.01	2.51	49
38.1x38.1	2.0, 2.5		1.32	1.57	1.78	2.13	2.75	49
40.0x40.0			1.43	1.67	1.89	2.26	3.06	49
50.8x50.8	2.0		1.81	2.10	2.40	3.94	3.69	49
65.0x65.0				2.78	3.08	3.58	4.78	30

Size (mm)	Product Type & Gauge (mm)	Finish	Nom Linear mass (kg/m)					Length per pack
Size (mm)	HR350	Finish	1.2	1.4	1.6	2.0	2.5	Length per pack
25.4x12.7			0.65	0.76	0.84	1.06		50
31.8x15.9			0.82	1.00	1.13	1.42		50
34.9x19.1			0.95	1.00	1.13	1.42		50
38.1x25.4			1.13	1.50	1.76	1.79	2.24	49
46.5x21.2			1.06	1.49	1.65	2.03	2.52	50
50.8x24.5	2.5		1.35	1.62	1.82	2.25	2.78	50
50.8x31.8			1.49	1.74	1.95	2.45	2.94	50
57.2x34.9			1.61	1.89	2.14	2.66	3.33	50
60.0x30.0			1.61	1.89	2.14	2.66	3.33	50
63.5x38.1			1.84	2.09	2.39	2.99	3.26	50
68.0x14.0			1.43	1.67	1.91	2.39		100
68.0x43.0			1.97	2.35	2.67	3.23	4.16	50
70.0x11.0			1.43	1.67	1.91	2.39		100

Size (mm)	Product Type & Gauge (mm)	Finish	Nom Linear mass (kg/m)					Length per pack
Size (mm)	HR250	Finish	1.2	1.4	1.6	2.0	2.5	Length per pack
19.0x12.0		OV	0.43	0.50	0.56	0.67		50
25.4x15.9		FSO	0.65	0.75	0.83	1.00		50
31.8x15.9		FSO	0.71	0.83	0.93	1.15		50
31.8x17.1	2.0	OV	0.71	0.83	0.93	1.15		50
32.0x22.0		OV	0.74	0.89	1.01	1.26		50
34.9x15.9		FSO	0.78	0.94	1.07	1.32		50
50.8x15.9		FSO	1.07	1.26	1.36	1.78		50
54.0x35.0		FSO	1.35	1.57	1.79	2.19	2.78	49
59.0x30.0		OV	1.35	1.57	1.79	2.19	2.78	49
72.0x45.0		FSO	1.81	2.14	2.42	3.02	3.85	42
97.0x42.0		FSO			2.89	3.59	4.54	24
